概述：應用概述 General of applications★高效無孔包衣機是用于制藥、食品工業的片劑、丸劑、微丸、水丸、滴丸、顆粒等包糖衣、有機薄膜衣、水溶性薄膜衣、緩釋、控釋包衣，特別適用于中西藥片，符合GMP要求?！颒igh Efficiency Poreless Coater is mainly

文章詳情

應用概述 General of applications

★高效無孔包衣機是用于制藥、食品工業的片劑、丸劑、微丸、水丸、滴丸、顆粒等包糖衣、有機薄膜衣、水溶性薄膜衣、緩釋、控釋包衣，特別適用于中西藥片，符合GMP要求。

★High Efficiency Poreless Coater is mainly used for tablet, capsule, pellet, water solving, dropping capsule, granule etc. to carry out organic film coating, water soluble film coating, slow and control releasing coating. Particularly it is suitable for Chinese traditional medicine and western medicine tablet. It conforms to the requirements of GMP.

設備特點 Features of equipment

★具備了BGB系列高效包衣機的所有特點。

★電腦控制、觸摸屏顯示。

★包衣滾筒為無孔結構，能耗低、用途廣。

★可對?0.6mm以上的素芯進行包衣。

★有機薄膜衣、水溶性薄膜衣、緩釋包衣、控釋包衣。

★進、排風管可按需要互換。

★風槳可根據工藝需要埋入或離開物料。

★具有特殊清洗排除裝置。

★Having all features of BGB Series High Efficiency Coater.

★Controlled by computer and displayed by touch screen.

★The drum of coating is poreless structure with low energy consumption and wide application.

★Can carry out coating to over ?0.6mm of pure core.

★Water soluble film coating, slow and control releasing coating.

★The inlet pipe and outlet pipe can be exchanged for organic film coating, water soluble film coating, slow releasing coating and control releasing coating in accordance with actual condition.

★The air oar can be immersed into and separated from material in accordance with actual condition.

★Having special device to clean and drain.

項目 ltem 規格 Specification		BGW10型	BGW40型	BGW80型	BGW150型
生產能力 (Kg/批) Capacity (Kg/batch)		10	40	80	150
滾筒轉速（轉/分） Speed of drum (rpm)		6-25	5-22	4-19	3-15
主機功率 Machine power (Kw)		0.55	0.75	1.5	2.2
主機體積(LxWxH) Machine dimensions (mm)		900×1170×1320	1000×1380×1540	1210×1800×1850	1450×2100×2100
包衣滾筒直徑 Diameter of coating platen (mm)		?600	?825	?1006	?1280
排風柜電機功率 Power of air exhaust cabinet motor (Kw)		0.75	2.2	3	5.5
熱風柜電機功率 Power of hot air cabinet motor (Kw)		0.55	0.75	1.1	1.5
加料口直徑 Diameter of charger port (mm)		260	340	380	458
風量 Air exhaust flow (m3/h)		＜700	＜2000	＜3600	＜4500
主機重量 Weight of main machine (Kg)		450	550	800	1000
熱風柜外型尺寸 Overall dimensions of hot air cabinet (LxWxH) (mm)		850×650×1950	900×800×1500	1000×900×1650	900×1000×1650
排風柜外型尺寸 Overall dimensions of air exhaust cabinet (LxWxH) (mm)		850×650×1950	820×720×1750	900×820×1850	950×950×1950
潔凈壓縮空氣 Compressed air	壓強 Pressure(Mpa)	≥0.4	≥0.4	≥0.4	≥0.4
潔凈壓縮空氣 Compressed air	耗氣量 Air consumpption(m3/min)	0.2	0.2	0.35	1.5

所有參數僅作參考，視物料情況，本公司擁有變更權利，并不另行通知。

All datas are used for reference only. According to the condition of material, our factory has the right to change but not notice, pardon!
